Industrial LCD Monitors – Metal or Plastic Housing, with many options Touch Screens

PMB2005CyberVisuell offers a massive range of high quality industrial LCD monitors, with several different chassis styles available in sizes ranging from 5.7″ up to 65″.
The monitors are built using a fully metal chassis, with stainless steel versions also available.

In addition, the range includes an unmatched array of monitor options, allowing custom configurations to meet individual requirements.
Option examples:
FME1505-small
• sunlight readable,
• composite video or HDMI inputs,
• AC or DC powered,
• various touch screen types,
• marine grade
 and so on.

The factory can supply monitors to Australia with custom combinations of options, even for very small orders, due to the highly modular design.



Overview of Monitor Styles

Please click on an image to view detailed product information.



SCB Smart Chassis (base model)SCB SmartChassis (base model)
(optional IP65 front)
SCD Smart Chassis with Front BracketsSCD SmartChassis with front mounting brackets
(optional IP65 front)
SCJ Smart Chassis IP65 Front, Stainless SteelSCJ SmartChassis IP65 Front Stainless Steel SCK Smart Chassis Full IP66 Stainless SteelSCK SmartChassis Full IP66 Stainless Steel
PMB Panel Mount, Rear OSD (base model)PMB Panel Mount, OSD Buttons on Side (base model)
(optional IP65 front)
PMC Panel Mount, Front OSD (base model)PMC Panel Mount, OSD Buttons on Front (base model)
(optional IP65 front)
Please click on an image to view detailed product information.
PMJ Panel Mount, IP65 Stainless Steel FrontPMJ Panel Mount, IP65 Stainless Steel Front
(OSD Buttons on Side)
RMB 19" Rack Mount (base model)RMB 19″ Rack Mount (base model)
(optional IP65 front)
OFB Open Frame (base model)OFB Open Frame (base model) FME  Flush Mount Marine GradeFME Flush Mount Marine Grade (IP65 front / IP54 rear)
PCB Plastic Case (base model, desktop style)PCB Pastic Case Desktop Monitor(base model) PCB1585 LCD Touch Monitor with plastic casePCC Plastic Case Touch Monitor (heavy stand for touch use)
See below for chart of Screen Sizes and Resolutions, Common Specs, and Options.
Please click on an image above
to view detailed product information.

Features

All models offer the following features:

  • Rugged metal chassis (except PCx series) with smart, clean appearance
  • Industrial grade for long lasting performance under constant usage
  • Wide range of options available with no MOQ, due to modular design
  • Optional IP65 waterproof front, and some models available fully IP66 sealed
  • Wide operating temperature 0-50°C
  • Touch screens: Resistive, Capacitive, SAW, Infra-Red, or Projected Capacitive, or vandal-proof glass
  • Flexible input options: VGA, DVI, HDMI, Composite Video, S-Video, HD-SDI or built-in Media Player
  • Optional built-in PC (Panel PC) with various processor options
  • Power options: DC 12V with mains adaptor, or AC input, or wide range DC input for vehicle use
  • Optional Sunlight Readable panel and/or LED backlight, with optional wide dimming range for marine/vehicle use
  • Various chassis designs allow wall mounting, panel mounting, free standing, rack mounting or kiosk integration
  • VESA compliant mounting on rear
  • OSD (On Screen Display) buttons can be located on front (panel/rack mount models only), on the side, or on a separate remote control



DVI / VGA Standards and Cabling

Cable for the image can be either VGA (15-pin) or DVI (Digital Video Interface, 24-pin).

DVI gives the highest image quality, but the computer must support the DVI interface.    DVI Information (opens in new tab)

DVI-D (digital only)    DVI-A (analog only)     DVI-I (integrated, digital & analog)

DVI-DL: The connector also includes provision for a second data link for high resolution displays, though some devices do not implement this. In those that do, the connector is sometimes referred to as DVI-DL (dual link).    Connector width: 37mm.

DVI PinoutThe DVI-I (24 + 4 pin connector) can transfer digital and analog signals which use C1 to C4 at the right.

This allows a VGA monitor with 15-pin D connector to be connected to DVI-I or DVI-A output with a simple plug adapter.

“Image phase adjustment” allows fine tuning of the image appearance.

The maximum length of DVI cables is not included in the specification since it is dependent on bandwidth requirements (the resolution of the image being transmitted).

In general, cable lengths up to 4.5 m (15 ft) will work for displays at resolutions of 1920 x 1200.

Cable lengths up to 15 m (50 ft) can be used with displays at resolutions up to 1280 x 1024.

For longer distances, to eliminate the video degradation, the use of a DVI booster or DVI extender is recommended. DVI boosters may or may not use an external power supply.



Brightness Units – Nits

One nit (unit of luminance) is equal to one candela per square meter (1 cd/m²), used to quote the brightness of computer displays.

Candela: A unit of measurement of the intensity of light.

1 candela = 1 lumen/steradian. Part of the SI system of measurement, one candela (cd) is the monochromatic radiation of 540THz (near green) with a radiant intensity of 1/683 watt per steradian in the same direction.

Another way of putting it is that an ordinary wax candle generates approximately one candela in any particular direction.

A light source that uniformly radiates one candela in all directions radiates a total of 4pi lumens.

A 100 W incandescent lightbulb emits about 120 cd.

Steradian (sr) A unit of measure equal to the solid angle subtended at the center of a sphere by an area on the surface of the sphere that is equal to the radius squared: The total solid angle of a sphere is 4pi steradians.

1 Lux = 1 lumen/square meter, the illumination of a surface.



Screen Sizes and Resolutions

4:3 Aspect Ratio
Wide Screen Aspect Ratio
Model No  Size  Res.
Pics of 5.7″ and 20.1″ Smart Chassis Model No   Size    Res. Pics of 7″ and 65″Smart Chassis
xxx refers to monitor style and IP rating options.

See below for xxx code.



xxx0576VN     5.7″ 640×480

xxx0656VN     6.5″ 640×480

xxx0846SN     8.4″ 800×600

xxx1045XN   10.4″ 1024×768

xxx1205XN   12.1″ 1024×768

xxx1505XN   15″  1024×768

xxx1705EN   17″ 1280×1024

xxx1905EN   19″ 1280×1024

xxx2005UN 20.1″ 1600×1200



Note:

Some monitor styles are only available in a limited range of sizes.

Other resolutions are also available in some sizes.

Please contact us for details.

xxx codes are below

MCB0576SMCB2005
xxx refers to monitor style and IP rating options.

See below for xxx code

xxx0706WV    7″      800×480

xxx0896WS   8.9″  1024×600

xxx1016WS   10.1″ 1024×600

xxx12W5WE 12.1″ 1280×800

xxx1545WE   15.4″ 1280×800

xxx17W5WP  17″ 1440×900

xxx19W5WP 19″   1440×900

xxx2205WM   22″ 1680×1050

xxx2405WH   24″ 1920×1080

xxx2415WU   24″ 1920×1200

xxx2605WX   26″  1366×768

xxx3205WH   32″  1920×1080

xxx3705WH   37″ 1920×1080

xxx4204WH   42″ 1920×1080

xxx4604WH   46″ 1920×1080

xxx5504WH  54.6″ 1920×1080

xxx6504WH   65″ 1920×1080

MCB0706MCB6504
xxx Codes

SCB SmartChassis (base model) (optional IP65 front)
SCD SmartChassis with front mnting brackets (opt IP65 front)
SCJ SmartChassis IP65 Front Stainless Steel
SCK Smart Chassis Full IP66 Stainless Steel

PMB Panel Mount, OSD Buttons on Side (optional IP65 front)
PMC Panel Mount, OSD Buttons on Front (optional IP65 front)
PMJ Panel Mount, IP65 Stainless Steel Front
                          (OSD Buttons on Side)

RMB 19″ Rack Mount (base model) (optional IP65 front)

OFB Open Frame (base model)
FME Flush Mount Marine Grade (IP65 front / IP54 rear)

PCB Pastic Case Desktop Monitor (base model)
PCC Plastic Case Touch Monitor (heavy stand for touch use)

Models with these codes are pictured above.



Common Specifications

Display Type
TFT LCD
Panel
Surface Black Anti-Glare, Low Reflection Coating
Light Source CCFL, (cold-cathode fluorescent lamps)
Long Life 50,000 Hrs (typ)
Optional LED Backlight available, various brightnesses
Inputs
VGA Input 15-pin D-Sub Female, Analog RGB Signal
0.7/1.0Vp-p, 75 Ohms, Fh = 30-82kHz, Fv = 50-75Hz
Separate Sync / Composite Sync / Sync on Green
Audio Stereo Mini Jack, 2W Speaker x2
Power
15″ models and above AC mains 90-260V auto sensing input
Up to 12″ / option on 15″-22″ 12V DC, with External AC Adaptor included
Mounting
VESA mount on rear Up to 17″: 75 x 75 mm
19″-24″: 100 x 100 mm
26″-37″: 400 x 200 mm
Features
Auto Calibration, Back Light Adjustment, Plug & Play (VESA DDC/CI, DDC 2B)
Operating Conditions
Temperature / Humidity 0°C to 50°C, 10%-90% (non condensing)
Storage Conditions
Temperature / Humidity -20°C to 60°C, 10%-90% (non condensing)
Certifications
CE, FCC, C-Tick CE, FCC, C-Tick



Options

Most options may be ordered in any quantity of monitors.

Please note some combinations of options/sizes may not be possible – please contact us for a quote.

Option Codes

Grades

Marine Grade – shock and vibration tolerant, anti-rust
For marine applications we also recommend using SCK stainless series or FME Marine Flush Mount series, with wide range DC input, sunlight readable, wide dimming range, and wide temperature options.

-GM

Vehicle Grade

– shock and vibration tolerant
For vehicle applications we also recommend using the wide range DC input, sunlight readable, and wide temperature options.
Wide dimming range may also be needed.

-GV
Panel / Backlight

LED Backlight with specified brightness “xxxx” nits
Use 0700 or 1000 nits for Sunlight Readable

-BLxxxx

CCFL Backlight with specified brightness “xxxx” nits

-BCxxxx

Wide Dimming Range, controlled by OSD buttons

-BW

Wide Dimming Range, controlled by knob

-BK
Touchscreens

USB connection by default, or specify -RS232 for serial

Infomation about Touchscreens
  (Wikipedia, in new tab)

Resistive

-TR

Capacitive (cannot detect gloved finger), optionally with 6mm Anti-Vandal Glass

-TC or -TC6

SAW (Surface Acoustic Wave)

-TS

Infra-Red

-TI

Projected Capacitive (can sense a passive stylus or gloved fingers) with 6mm Anti-Vandal Glass

-TP6

Protective Glass (no touch): 3mm, or 6mm Anti-Vandal

-TG3 or -TG6
Inputs

VGA

-IV

VGA + DVI

-IVD

VGA + DVI + HDMI

-IVDH

VGA + DVI + HDMI + RS-232 remote control input

-IVDHR

VGA + S-Video + Composite Video (BNC connectors)

-IVSC

VGA + S-Video + Composite Video with Looping Output (BNC connectors)

-IVSCL

VGA + DVI + S-Video + Composite Video

-IVDSC

VGA + HDMI + Composite Video with Looping Output

-IVHCL

VGA + HDMI

-IVH

VGA + Media Player (plays various formats from CF / SD cards / USB stick)

-IVM
Power

AC mains 90-260V auto sensing input (only for 15″ and higher)

-P240

12V DC, with External AC Adaptor included

-P12

Wide voltage range DC power input

-PW
Mount Options

Does not include any stand or bracket

-MN

Includes stand (Plastic monitors only)

-MS

Clamp Mount (for Panel Mount monitors) – clamping blocks supplied for easy mounting into a panel without screw holes

-MC

Includes marine style multi-tilt mounting brackets (FME series only)

-MB
Other Options

Wide Temperature Range

-RW

Wide Viewing Angle

-VW

Light Sensor with auto dimming

-LS

OSD buttons on a wired Remote Control box

-OR

Integrated PC (Panel PC / Digital Signage Platform)

Options include Fanless Atom N270, Atom D525, Core 2 Duo, Core 2 Quad, Core i5, Core i7
